Introducing the HAEXC SP104Ex – Rugged Performance Meets Smart Mobility for Hazardous Zones

The HAEXC SP104Ex is a powerful 4G intrinsically safe smartphone designed for Zone 1/21 hazardous areas. It merges industrial-grade toughness with advanced Android functionality, delivering a modern solution for high-risk environments where safety and performance cannot be compromised.

Features

Powered by Android 14 and a MediaTek Octa-Core 2.2 GHz processor, the SP104Ex supports seamless app performance and system stability. It comes equipped with 6 GB RAM and 128 GB storage, enabling smooth multitasking and ample space for mission-critical applications.

ATEX and IECEx Certified by TUV Rheinland GmbH, the SP104Ex withstands extreme temperatures (-20 °C to +55 °C) and harsh conditions with IP68 protection and 1.2m drop resistance. A powerful removable 4000mAh battery ensures long-lasting operation in the field, supported by a full set of accessories for easy deployment.

Technical Features

Operating System: Android™ 14
Processor: MediaTek 6765 Octa Core 2.2 GHz
Memory: RAM 6GB + ROM 128GB

Frequencies:
LTE: B1/2/3/4/5/7/8/18/19/20/26/28a&b/34/38/3940/41
WCDMA: B1/5/8
GSM: 850/900/1800/1900

Dimensions: 148 x 70.5 x 25 (mm), 325g

Display: 4.0” LCD, 540x1080(VGA), Multi-Point Capacitive Gorilla Glass (Impact & Scratch Resistance), Support Glove Mode

Battery: Li-Ion, 4000mAh, Replaceable

Camera: 8MP Front Camera, 50MP Rear Camera (Auto Focus)

Connectivity:
Dual SIM (Nano), VoLTE
Wi-Fi 802.11 ac/a/b/g/n. Dual Wi-Fi 2.4 GHz & 5 GHz
Bluetooth 5.1 (Bluetooth Low Energy)
GPS/A-GPS/BeiDou/GLONASS/Galileo
NFC (Near Field Communication)
Type-C USB

Degree of Protection: IP68 (Water & Dust), Drop Test 1.2 m, Ta = -20 °C to +55 °C

Additional Features

With a vibrant 4.0” Gorilla Glass touchscreen, support for glove mode, and dedicated PTT/SOS/FN keys, the SP104Ex is purpose-built for field communication. Enhanced by Bluetooth 5.1, dual-band Wi-Fi, NFC, and GNSS positioning (GPS, GLONASS, BeiDou, Galileo), it ensures complete connectivity even in remote areas.

Featuring a high-resolution 50 MP rear camera, AI noise reduction microphones, and waterproof speaker, the SP104Ex empowers workers with smarter, safer communication.

Package Content

SP104Ex Smart Phone
4000mAh Li-Ion Battery
Travel Charger (with Multi-Adaptors)
Type-C USB Cable
Magnetic USB Cable
Docking Station
Wrist Strap
Screwdriver
Documents

Approvals

ATEX (Europe)
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T130°C Db
Ta = -20 °C to +55 °C

IECEx (International)
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T130°C Db
Ta = -20 °C to +55 °C
