Rs Pro 7110842 1000 Microfarad Aluminium Electrolytic Capacitor 10V Dc, Radial, Through Hole

View Brand

Rs Pro 7110842 1000 Microfarad Aluminium Electrolytic Capacitor 10V Dc, Radial, Through Hole

Brand:	RS Pro
Model:	7110842

Technical Data Sheets

RS Pro Datasheet

Specifications

View other Aluminium Capacitors dimensions or variations

Voltage

10 VDC

Mounting Type

Radial, Through Hole

Dimensions

8 (Dia.) x 14 mm

Capacitance

1000 µF

Lead Pitch

3.5 mm

Lifetime

2000h

Ripple Current

500 mA

Leakage Current

<=0.01 CV or 3 µA @ 1 min

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+105°C

Dissipation Factor

20%

Tolerance

±20%

Product Description

S$ 4.60

(exc. GST)

S$ 5.01

(inc. GST)

Units	Discount	Unit Price
1	-	S$ 0.18

Quantity:

MOQ of 25 EA

Bundle of 25 EA

This item is sold by

SG-4570630354
