Rs Pro 1815071 220 Microfarad Aluminium Electrolytic Capacitor 25V Dc, Radial, Through Hole

View Brand

Rs Pro 1815071 220 Microfarad Aluminium Electrolytic Capacitor 25V Dc, Radial, Through Hole

Brand:	RS Pro
Model:	1815071

Technical Data Sheets

RS PRO Datasheet

Specifications

View other Aluminium Capacitors dimensions or variations

Voltage

25 VDC

Mounting Type

Radial, Through Hole

Dimensions

10 (Dia.) x 12 mm

Capacitance

220 µF

Lead Pitch

5 mm

Lifetime

1000h

Ripple Current

600 mA

Leakage Current

3 µA

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+105°C

Dissipation Factor

14%

Tolerance

±20%

Product Description

S$ 188.00

(exc. GST)

S$ 204.92

(inc. GST)

Units	Discount	Unit Price
1	-	S$ 0.19

Quantity:

MOQ of 1000 EA

Bundle of 1000 EA

This item is sold by

SG-4570630354
