Specifications
Please select at least one specification below.
Standards
UL Listed
Operating Pressure Differential - Minimum
0 psi
Valve Starting Configuration
Normally Closed
Operating Temperature - Maximum
180°F
Nominal Pipe Size
1/8"
Operating Pressure Differential Light Oil - Maximum
300 psi
Operating Pressure Differential Water - Maximum
300 psi
Body Material
Brass
Seal Material
NBR
Operating Pressure Differential Air/Inert Gas - Maximum
300 psi
Environmental Rating
Outdoor, Indoor
This spec is not available in the specification table.
Orifice Diameter
3/32"
This spec is not available in the specification table.
Valve Ways
2-Way
This spec is not available in the specification table.
For Media
Water, Steam, Air, Light Oil
This spec is not available in the specification table.
Operation Type
Direct Acting
This spec is not available in the specification table.
Connection Type
NPT x NPT
This spec is not available in the specification table.
Fluid Temperature - Maximum
180°F
This spec is not available in the specification table.
Coefficient of Volume (Cv)
0.22, 0 - 0.50
This spec is not available in the specification table.
Product Description
S$ 149.78
(exc. GST)
S$ 163.26
(inc. GST)
| Units | Discount | Unit Price |
|---|---|---|
| 1 | - | S$ 149.78 |
Quantity:
EA
Lead time of 18 working days required.
Item will be ready to dispatch within the lead time specified.
This item is sold by
SG-4667031604
